| Material | Nickel-plated brass |
| Clamping insert | Polyamide |
| Seal | NBR |
| Protection class |
IP 68, IP68 - 10bar/30min, IP 69 K |
| Temperature range | -40°C to +100°C |
| Variant | PG |
| External thread (AG) | PG 16 |
| Cable diameter | 7 – 12 mm |
| D | 29 mm |
| Thread length (GL) | 6.5 mm |
| Height (H) | 40.5 mm |
| Wrench size (SW) | 28 mm |
| Suitable for polyamide hose DN | 14 |
