| Material | Nickel-plated brass |
| Seal | NBR |
| Protection class |
IP 54, IP 65 in case of additional flat seal at connection thread |
| Temperature range | -20°C to +80°C |
| Variant | PG |
| External thread (AG) | PG 9 |
| Cable diameter | 4 – 10 mm |
| Thread length (GL) | 7 mm |
| Height (H) | 17 mm |
| Wrench size (SW1/SW2) | 15/17 mm |
| E | 6 mm |
| Product group | EMC |
| incognito | ja |
