| Material | Brass |
| Seal | VMQ (silicone) |
| Material o-ring | VMQ (silicone) |
| Clamping insert | Polyamide 6 |
| Protection class |
IP 66, IP 67, IP 68 - 5bar/30min |
| Ex-protection level |
Class I Div 2 Groups A,B,C,D, Class II Div 1 Groups E,F,G, II 1D Ex ta IIIC Da, II 2G Ex db eb IIC Gb |
| Temperature range | -60°C to +105°C |
| Variant | Metric |
| External thread (AG) | M20 x 1,5 |
| Size | 20-1 |
| A1 | 6 – 12 mm |
| Thread length (GL) | 16 mm |
| Height (H) | 35.6 mm |
| Wrench size (SW1/SW2) | 22/22 mm |
| D | 27 mm |
| Tightening torque | 8 Nm |
| Product group |
Ex d, Ex e |
