Certificates & approvals for cable glands

Assignment: Cable gland - approval

Which cable gland has which approval? The following table gives an overview. The products are divided according to product name, article number and - very important - temperature ranges.

Article	Number	Temperature	EC-Type Examination Certificate
EXIOS A2F	1.608.*	- 60°C – 105°C	DEKRA 12 ATEX 0139 X
EXIOS Barrier	1.606.*	- 60°C – 85°C	Sira 11 ATEX 1110 X
EXIOS Standard	1.605.*	- 60°C – 105°C	BVS 10 ATEX E 062 X
HSK-INOX-Ex	1.612.*	- 20 °C – 95 °C	DMT 03 ATEX E 051 X
HSK-INOX-Ex	1.642.*	- 60 °C – 95 °C	KEMA 99 ATEX 6971 X
HSK-INOX-Ex d	1.632.*	- 60 °C – 105 °C	KEMA 99 ATEX 6968 X
HSK-INOX-PVDF-Ex	1.662.*	- 20 °C – 130 °C	KEMA 99 ATEX 6971 X
HSK-INOX-PVDF-Ex d	1.633.*	- 20 °C – 130 °C	KEMA 99 ATEX 6968 X
HSK-K-Ex-Active	1.292.*	- 20 °C – 85 °C	BVS 14 ATEX E 025 X
HSK-K-MZ-Ex	1.215.*	- 20 °C – 70 °C	KEMA 99 ATEX 6971 X
HSK-M-EMC-D-Ex	1.636.*	- 20 °C – 95 °C	DMT 03 ATEX E 051 X
HSK-M-EMC-D-Ex	1.637.*	- 60 °C – 95 °C	KEMA 99 ATEX 6971 X
HSK-M-EMC-PVDF-Ex	1.666.*	- 20 °C – 130 °C	KEMA 99 ATEX 6971 X
HSK-M-Ex d	1.622.*	- 60 °C – 105 °C	KEMA 99 ATEX 6968 X
HSK-M-Ex HSK-M-EMC-Ex	1.610.* 1.616.*	- 20 °C – 95 °C	DMT 03 ATEX E 051 X
HSK-M-Ex HSK-M-EMC-Ex	1.640.* 1.646.*	- 60 °C – 95 °C	KEMA 99 ATEX 6971 X
HSK-M-Flaka-Ex	1.689.*	- 20 °C – 95 °C	DMT 03 ATEX E 051 X
HSK-M-Multi-Ex	1.687.*	- 20 °C – 95 °C	DMT 03 ATEX E 051 X
HSK-M-PVDF-Ex	1.660.*	- 20 °C – 130 °C	KEMA 99 ATEX 6971 X
HSK-M-PVDF-Ex d	1.634.*	- 20 °C – 130 °C	KEMA 99 ATEX 6968 X
HSK-MZ-EMC-Ex	1.647.*	- 60 °C – 95 °C	KEMA 99 ATEX 6971 X
HSK-MZ-EMC-PVDF-Ex	1.667.*	- 20 °C – 130 °C	KEMA 99 ATEX 6971 X
HSK-MZ-Ex d	1.628.*	- 60 °C – 105 °C	KEMA 99 ATEX 6968 X
HSK-MZ-Ex HSK-MZ-EMC-Ex	1.611.* 1.617.*	- 20 °C – 95 °C	DMT 03 ATEX E 051 X
HSK-MZ-PVDF-Ex	1.661.*	- 20 °C – 130 °C	KEMA 99 ATEX 6971 X
HSK-V-Ex / HSK-V-Ex Mz	1.296.*	- 20 °C – 95 °C	BVS 03 ATEX E 298 X
RSD-INOX-Ex	1.098.*	- 20 °C – 180 °C	DMT 03 ATEX E 049
RSD-INOX-Ex	1.099.*	- 60 °C – 180 °C	DMT 03 ATEX E 049
RSD-Ms- Ex d RSD-Ms-INOX-Ex d	1.879.* 1.899.*	- 60 °C – 180 °C	KEMA 06 ATEX 0024
RSD-Ms-Ex	1.078.*	- 20 °C – 95 °C	DMT 03 ATEX E 049
RSD-Ms-Ex	1.079.*	- 60 °C – 180 °C	DMT 03 ATEX E 049
RSD-Ms-Ex d RSD-Ms-INOX-Ex d	1.878.* 1.898.*	- 20 °C – 95 °C	KEMA 06 ATEX 0024
V-Ex	1.297.*	- 20 °C – 90 °C	DMT 03 ATEX E 049
V-INOX-Ex	1.192.*	- 20 °C – 95 °C	DMT 03 ATEX E 049
V-INOX-FKM-Ex	1.193.*	- 20 °C – 180 °C	DMT 03 ATEX E 049
V-INOX-VMQ-Ex	1.194.*	- 60 °C – 180 °C	DMT 03 ATEX E 049
V-Ms-Ex	1.197.*	- 20 °C – 95 °C	DMT 03 ATEX E 049
V-Ms-Ex d V-Ms-INOX-Ex d	1.875.* 1.895.*	- 20 °C – 95 °C	KEMA 06 ATEX 0024
V-Ms-Ex d V-Ms-INOX-VMQ-Ex d	1.877.* 1.897.*	- 60 °C – 180 °C	KEMA 06 ATEX 0024
V-Ms-Ex d V-Ms-INOX-FKM-Ex d	1.876.* 1.896.*	- 20 °C – 180 °C	KEMA 06 ATEX 0024
V-Ms-FKM-Ex	1.198.*	- 20 °C – 180 °C	DMT 03 ATEX E 049
V-Ms-VMQ-Ex	1.199.*	- 60 °C – 180 °C	DMT 03 ATEX E 049

IP 69K

IP 69K

ABS

ABS-16-HG1564219-PDA

ATEX for Europe

BVS	BVS_18_ATEX_ZQS_E195	deutsch	english
	BVS_10_ATEX_E_062X	deutsch	english	CE_BVS10ATEXE062X
	BVS_14_ATEX_E_025X	deutsch	english	CE_BVS14ATEXE025X
	BVS_03_ATEX_E_298X	deutsch	english	CE_BVS03ATEXE298X

DEKRA	DEKRA-12ATEX0139-X	deutsch	english	CE_DEKRA12ATEX0139X

DMT	DMT_03_ATEX_E_049	deutsch	english	CE_DMT03ATEXE049
	DMT_03_ATEX_E_051X	deutsch	english	CE_DMT03ATEXE051X

KEMA	KEMA_06_ATEX_0024	deutsch	english	CE_KEMA06ATEX0024
	KEMA_99_ATEX_6968X	deutsch	english	CE_KEMA99ATEX6968X
	KEMA_99_ATEX_6971X	deutsch	english	CE_KEMA99ATEX6971X

SIRA	Sira-11_ATEX_1110X		english	CE_SIRA11ATEX1110X

ATEX for Brazil (INMETRO)

TÜV-11_0136	TÜV-12_0175 X	TÜV-13 0800 X
TÜV-11_0137X	TÜV-12_0219 X	TÜV-14_1646 X
TÜV-11_0138 X	TÜV-12_0220	TÜV-16_2344 X
TÜV-11_0174	TÜV-12_0321 X
TÜV-11_0290	TÜV-12_0661 X
	TÜV-12_0662 X
	TÜV-12_0663 X
	TÜV-12_0664 X
	TÜV-12_0882 X
	TÜV-12_1261 X
	TÜV-12_1912 X

ATEX for China (CCC)

2021012313368490	V-Ms-Ex-d / V-INOX-Ex-d
2021012313368909	RSD-INOX-Ex-d / RSD-Ms-Ex-d
2021012313369918	V-Ex / V-Ms-VMQ-Ex / V-Ms-FPM-Ex / V-Ms-Ex / V-INOX-Ex
2021012313369920	HSK-M-Ex / HSK-M-EMV-Ex / HSK-M-EMV-D-Ex / HSK-MZ-Ex / HSK-MZ-EMV-Ex / HSK-INOX-Ex / HSK-M-Multi-Ex / HSK-M-Flaka-Ex / HSK-M-Ex / HSK-INOX-EMV-Ex / HSK-INOX-Ex
2021012313369921	HSK-V-Ex
2021012313369922	EXIOS-A2F
2021012313369923	HSK-K-Ex-Active / HSK-K-Multi-Ex-Active / HSK-K-Flaka-Ex-Active
2021012313369924	EXIOS-Barrier
2021012313369925	EXIOS-Standard / EXIOS-MZ
2021012313369926	HSK-K-MZ-Ex / HSK-M-Ex / HSK-M-PVDF-Ex / HSK-M-EMV-Ex / HSK-M-PVDF-EMV-Ex / HSK-M-EMV-D-Ex / HSK-MZ-Ex / HSK-MZ-PVDF-Ex / HSK-MZ-EMV-Ex / HSK-MZ-PVDF-EMV-Ex / HSK-INOX-Ex / HSK-INOX-PVDF-Ex / HSK-INOX-EMV-Ex / HSK-INOX-PVDF-EMV-Ex
2021012313369935	RSD-MS-Ex / RSD-INOX-Ex
2021012313369937	HSK-M-Ex-d / HSK-MZ-Ex-d / HSK-INOX-Ex-d / HSK-M-PVDF-Ex-d / HSK-INOX-PVDF-Ex-d

ATEX for Korea

12014-038023-01

Bahnzulassung / Railway authorities license

Bahnzulassung/Railway authorities license DIN EN 45545-3 M20 – M40
Bahnzulassung/Railway authorities license DIN EN 45545-3 M12, M16, M50, M63

CE

EU-Konformitätserklärung/EU-Declaration of Conformity 2014/34/EU

BVS	CE_BVS03ATEXE298X
	CE_BVS10ATEXE062X
	CE_BVS14ATEXE025X

DEKRA	CE_DEKRA12ATEX0139X

DMT	CE_DMT03ATEXE049
	CE_DMT03ATEXE051X

KEMA	CE_KEMA06ATEX0024
	CE_KEMA99ATEX6968X
	CE_KEMA99ATEX6971X

SIRA	CE_SIRA11ATEX1110X

EU-Konformitätserklärung/EU-Declaration of Conformity 2014/35/EU

DIN	CE_DIN
HSK-INOX	CE_HSK-INOX
HSK-K	CE_HSK-K
HSK-M	CE_HSK-M
VariaPro	CE_VariaPro
WADI Mini/XL	CE_WADI_MINI_XL

CSA

DNV

ECOLAB

IEC Ex

HSK-K-Ex 129.0.**		IECEx BVS 07.0020X
Kabelverschraubungen/Cabel glands: HSK-M-Ex 1610.**. HSK-M-EMV-Ex 1616.**. HSK-M-EMV-D-Ex 1631.**. HSK-MZ-Ex 1611.**. HSK-MZ-EMV-Ex 1617.**. HSK-INOX-Ex 1612.**. HSK-INOX-EMV-Ex 1672.**. HSK-M-Multi-Ex 1687.**. HSK-M-FLAKA-Ex 1689.**.		IECEx BVS 07.0019X
Verschlüsse und Reduktionen/Seals and reductions: RD-MS-Ex 1.078.**. V-MS-Ex 1.197.**. V-MS-Ex 1.198.**. V-Ex 1.297.**. RSD-MS-Ex 1.079.**. V-MS-Ex 1.199.**.		IECEx BVS 07.0021
Verschlüsse/Seals: HSK-V-Ex		IECEx BVS 07.0022X
EXIOS		IECEx BVS 10.0078X
HSK-K-Ex-Active		IECEx BVS 14.0020X
EXIOS A2F		IECEx DEK 12.0039X
Reduktionen/Reductions: RSD-Ms-Ex-d and RSD-INOX-Ex-d		IECEx KEM 06.0056
Verschlüsse/Seals: V-Ms-Ex-d V-INOX-Ex-d		IECEx KEM 07.0012
Kabelverschraubungen/Cable glands: HSK-M-Ex-d HSK-MZ-Ex-d HSK-MZ-PVDF-Ex-d HSK-INOX-Ex-d HSK-M-PVDF-Ex-d HSK-INOX-PVDF-Ex-d		IECEx KEM 07.0013X
Kabelverschraubungen/Cable glands: HSK-K-MZ-Ex HSK-M-Ex HSK-M-PVDF-Ex HSK-M-EMV-Ex HSK-M-EMV-PVDF-Ex HSK-M-EMV-D-Ex HSK-MZ-Ex HSK-MZ-PVDF-Ex HSK-MZ-EMV-Ex HSK-MZ-EMV-PVDF-Ex HSK-INOX-Ex HSK-INOX-PVDF-Ex HSK-INOX-EMV-Ex HSK-INOX-EMV-PVDF-Ex		IECEx KEM 07.0014X
EXIOS Barrier		IECEx SIR 11.0044X

UKCA

UKCA-UKEx

BVS	BVS03ATEXE298X	UKCA_BVS03ATEXE298X
	BVS10ATEXE062X	UKCA_BVS10ATEXE062X
	BVS11ATEXE132U	UKCA_BVS11ATEXE132U
	BVS14ATEXE025X	UKCA_BVS14ATEXE025X
	BVS15ATEXE051X	UKCA_BVS15ATEXE051X
	BVS21ATEXE010X	UKCA_BVS21ATEXE010X

DEKRA	DEKRA12ATEX0139X	UKCA_DEKRA12ATEX0139X

DMT	DMT03ATEXE049	UKCA_DMT03ATEXE049
	DMT03ATEXE051X	UKCA_DMT03ATEXE051X

KEMA	KEMA06ATEX0024	UKCA_KEMA06ATEX0024
	KEMA99ATEX6968X	UKCA_KEMA99ATEX6968X
	KEMA99ATEX6971X	UKCA_KEMA99ATEX6971X

SIRA	SIRA11ATEX1110X	UKCA_SIRA11ATEX1110X

UL

HSK UL Zertifikat

cUL

HSK CUL Zertifikat

UR

HSK UR Zertifikat

cUR

HSK CUR Zertifikat

VDE
